The expansion joint series 1505, elastomer, length 130, with galvanised steel flanges, PN10 flanged attachment, single bellows EPDM, hardened steel cable for water supply and distribution networks.
| Specification | Value |
|---|---|
| DN inches NPS | 1''1/4 |
| Flange or fitting material | Electro-zinc plated steel |
| Application | Water supply / Irrigation / Watering |
| DN | DN32 - 1''1/4 |
| Face to Face (mm) | 130.0 |
| Fluid | Cold water |
| Body material | EPDM |
| PS (bar) | 16 |
| Connections | With rotating flanges PN10/16 |
| TS max (°C) | 100 |
| TS min (°C) | -10 |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| With rotating flanges PN10/16 EPDM DN32 - 1''1/4 Electro-zinc plated steel | 1505032 | S1011542 |
€35.26
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN32 - 1''1/4 Stainless steel 316 | 1505033 | S1011543 |
€111.76
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN40 - 1''1/2 Electro-zinc plated steel | 1505040 | S1011544 |
€35.26
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN40 - 1''1/2 Stainless steel 316 | 1505041 | S1011545 |
€116.69
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN50 - 2'' Electro-zinc plated steel | 1505050 | S1011546 |
€35.26
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN50 - 2'' Stainless steel 316 | 1505051 | S1011547 |
€134.04
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN65 - 2''1/2 Electro-zinc plated steel | 1505065 | S1011548 |
€40.29
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN65 - 2''1/2 Stainless steel 316 | 1505066 | S1011549 |
€154.49
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN80 - 3'' Electro-zinc plated steel | 1505080 | S1011550 |
€45.63
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN80 - 3'' Stainless steel 316 | 1505081 | S1011551 |
€175.04
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN100 - 4'' Electro-zinc plated steel | 1505100 | S1011552 |
€51.91
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN100 - 4'' Stainless steel 316 | 1505101 | S1011553 |
€211.30
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN125 - 5'' Electro-zinc plated steel | 1505125 | S1011554 |
€76.10
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN125 - 5'' Stainless steel 316 | 1505126 | S1011555 |
€265.83
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN150 - 6'' Electro-zinc plated steel | 1505150 | S1011556 |
€86.86
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN150 - 6'' Stainless steel 316 | 1505151 | S1011557 |
€372.60
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN200 - 8'' Electro-zinc plated steel | 1505200 | S1011558 |
€134.84
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN200 - 8'' Stainless steel 316 | 1505201 | S1011559 |
€502.10
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN250 - 10'' Electro-zinc plated steel | 1505250 | S1011560 |
€205.86
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN250 - 10'' Stainless steel 316 | 1505251 | S1011561 |
€588.17
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN300 - 12'' Electro-zinc plated steel | 1505300 | S1011562 |
€228.20
(excl. btw)
|
add to cart |
| With rotating flanges PN10/16 EPDM DN300 - 12'' Stainless steel 316 | 1505301 | S1011563 |
€667.74
(excl. btw)
|
add to cart |
